全自动烫金机，热转印烫金机，烫金机价格，平面烫金机H-250

分享到：

气动平面/曲面烫金机H-400S Pneumatic flat/cylindrical hot stamping machine

产品名称：气动平面/曲面烫金机 Pneumatic flat/cylindrical hot stamping machine
language="javascript" src="HitCount.asp?id=125&LX=Qianbo_Products" type="text/javascript"> language="javascript" src="HitCount.asp?action=count&LX=Qianbo_Products&id=125" type="text/javascript">

更多产品图片：

产品详细介绍

H-400S 气动平面/曲面烫金机 Pneumatic flat/cylindrical hot stamping machine

H-400S 气动平面/曲面烫金机 功能特点

1 西门子LOGO！控制器控制，确保机器运行稳定可靠。
2 采用欧姆龙温控器，确保发热温度稳定，保证烫印质量。
3 曲肘机构设计，压缩空气消耗少，压力强劲。
4 烫印压力、温度、烫压时间可调。
5 工作台可自动前后移动，便于安全快速操作。
6 工作台可前后、左右、旋转调节。
7 自动送纸、收纸，并可调。
8 加装光电管（电眼）后可对带接点的热转印纸进行跟踪到位控制。
9 烫印头高度升降可调，可烫印较大的工作。
10 使用风油转换装置，梭动工作台带动工件平稳旋转烫印。
11 设有安全防护装置，保障操作者的安全。

H-400S 气动平面/曲面烫金机 技术参数

烫板面积:300×400mm
烫板高度调节量: 200mm
烫印最大整圆直径: φ125mm
烫印温度选择范围: 室温~280度
烫金纸卷绕长度: ≤450mm
最大烫印压力: 2500kgf (7bar)
最大烫印速度: 500pcs/hr
电源: 110/220V 60/50Hz
发热功率: 3000W
耗气量 :150L/min
外形尺寸: 870×1272×1785mm
重量: 330kg

Feature

1.Microprocessor control together with LCD display (English version available) for easy operation;
2.Stamping pressure/temperature/time all adjustable;
3.Crank mechanism design provides strong pressure with little loss;
4.5-digit auto counter built in;
5.Worktable moves lengthwise automatically. It is good for safe and quick operation;
6.Adjustment available on worktable front/rear, left/right and plane angle;
7.Foil feeding and collecting are automatic and adjustable;
8.The foil with dots can be traced and controlled with a photo sensor installed;
9.Protecting device ensures the operator’s safety;
10.The adjusting range of stamp height is wide, so substrate with large size can be printed.
11.Pneumatic-hydraulic conversion system enables worktable to take substrate to rotate smoothly, and print quality is consistent.

Parameter

Max. stamping pressure: 24500N;
Max. stamping diameter: φ125mm;
Size of stamping plate: 300mm×400mm;
Stamping temperature adjustable range: 0-280℃;
Heating wattage: 3000W;
Stamping foil winding length: ≤450 mm;
Max. stamping speed: 500pcs/hr;
Air consumption: 150Litre/min;
Power: 110/220V 60/50Hz;
Outline dimension: 870×1272×1785mm;
Weight: 330Kg.

气动平面烫金机H-400 Pneumatic flat hot stamping machine

产品名称：气动平面烫金机 Pneumatic flat hot stamping machine

language="javascript" src="HitCount.asp?id=124&LX=Qianbo_Products" type="text/javascript"> language="javascript" src="HitCount.asp?action=count&LX=Qianbo_Products&id=124" type="text/javascript">

更多产品图片：

产品详细介绍

H-400 气动平面烫金机 Pneumatic flat hot stamping machine

H-400 气动平面烫金机功能特点

1 西门子LOGO！控制器控制，确保机器运行稳定可靠。
2 采用欧姆龙温控器，确保发热温度稳定，保证烫印质量。
3 曲肘机构设计，压缩空气消耗少，压力强劲。
4 烫印压力、温度、烫压时间可调。
5 工作台可自动前后移动，便于安全快速操作。
6 工作台可前后、左右、旋转调节。
7 自动送纸、收纸，并可调。
8 加装光电管（电眼）后可对带接点的热转印纸进行跟踪到位控制。
9 烫印头高度升降可调，可烫印较大的工作。
10 设有安全防护装置，保障操作者的安全。

H-400 气动平面烫金机技术参数

烫板面积:300×400mm
烫板高度调节量: 300mm
烫印温度选择范围: 室温~280度
烫金纸卷绕长度: ≤450mm
最大烫印压力 :2500kgf (7bar)
最大烫印速度: 900pcs/hr
电源: 110/220V 60/50Hz
发热功率: 3000W
耗气量 :142L/min
外形尺寸: 870×1050×1760mm
重量: 300kg

Feature

1.Siemens LOGO PLC is used for control together with LCD display to ensure high reliability and stability;
2.Omron Temp.Controller is adopted, so temp.control is accurate and reliable;
3.Adjustment on stamping pressure, temperature and speed available;
4.Crank mechanism design provides strong pressure with little loss;
5.5-digit auto counter built in;
6.Worktable moves lengthwise automatically. It is good for safe and quick operation;
7.Adjustment available on worktable front/rear, left/right and plane angle;
8.Foil feeding and collecting are automatic and adjustable;
9.The foil with dots can be traced and controlled with a photo sensor installed;
10.Protecting device ensures the operator’s safety;
11.The adjusting range of stamp height is wide, so substrate with large size can be printed.

Parameter

Max. stamping pressure: 24500N;
Max. stamping height: 380mm;
Size of stamping plate: 300mm×400mm;
Stamping temperature adjustable range: 0-280℃;
Heating wattage: 3000W;
Stamping foil winding length: ≤450 mm;
Max. stamping speed: 900pcs/hr;
Air consumption: 142Litre/min;
Power: 110/220V 60/50Hz;
Outline dimension: 870×1050×1785mm;
Weight: 300Kg.

气动平面/曲面烫金机H-250S Pneumatic flat/cylindrical hot stamping machine

产品名称：气动平面/曲面烫金机 Pneumatic flat/cylindrical hot stamping machine
language="javascript" src="HitCount.asp?id=123&LX=Qianbo_Products" type="text/javascript"> language="javascript" src="HitCount.asp?action=count&LX=Qianbo_Products&id=123" type="text/javascript">

更多产品图片：

产品详细介绍

H-250S 气动平面/曲面烫金机 Pneumatic flat/cylindrical hot stamping machine

H-250S 气动平面/曲面烫金机功能特点

1 西门子LOGO！控制器控制，确保机器运行稳定可靠。
2 采用欧姆龙温控器，确保发热温度稳定，保证烫印质量。
3 曲肘机构设计，压缩空气消耗少，压力强劲。
4 烫印压力、温度、烫压时间可调。
5 工作台可自动前后移动，便于安全快速操作。
6 工作台可前后、左右、旋转调节。
7 自动送纸、收纸，并可调。
8 加装光电管（电眼）后可对带接点的热转印纸进行跟踪到位控制。
9 烫印头高度升降可调，可烫印较大的工作。
10 使用风油转换装置，梭动工作台带动工件平稳旋转烫印，烫印质量稳定。
11 设有安全防护装置，保障操作者的安全。

H-250S 气动平面/曲面烫金机技术参数

烫板面积:180×230mm
烫板高度调节量:200mm
烫印最大整圆直径: φ70mm
烫印温度选择范围 :室温~280度
烫金纸卷绕长度: ≤300mm
最大烫印压力: 2000kgf
最大烫印速度: 600pcs/hr
电源: 110/220V 60/50Hz
发热功率 :2000W
耗气量 :180L/min
外形尺寸: 650×1120×1750mm
重量 :302kg

Feature

1.Microprocessor control together with LCD display (English version available) for easy operation;
2.Stamping pressure/temperature/time all adjustable;
3.Crank mechanism design provides strong pressure with little loss;
4.5-digit auto counter built in;
5.Worktable moves lengthwise automatically. It is good for safe and quick operation;
6.Adjustment available on worktable front/rear, left/right and plane angle;
7.Foil feeding and collecting are automatic and adjustable;
8.The foil with dots can be traced and controlled with a photo sensor installed;
9.Protecting device ensures the operator’s safety;
10.The adjusting range of stamp height is wide, so substrate with large size can be printed.
11.Pneumatic-hydraulic conversion system enables worktable to take substrate to rotate smoothly, and print quality is consistent.

Parameter

Max. stamping pressure: 19600N;
Max. stamping diameter: φ105mm;
Size of stamping plate: 180mm×230mm;
Stamping temperature adjustable range: 0-280℃;
Heating wattage: 2000W;
Stamping foil winding length: ≤300 mm;
Max. stamping speed: 600pcs/hr;
Air consumption: 180Litre/min;
Power: 110/220V 60/50Hz;
Outline dimension: 650×1120×1650mm;
Weight: 302Kg.

气动平面烫金机H-250 Pneumatic flat hot stamping machine

产品名称：气动平面烫金机 Pneumatic flat hot stamping machine
language="javascript" src="HitCount.asp?id=122&LX=Qianbo_Products" type="text/javascript"> language="javascript" src="HitCount.asp?action=count&LX=Qianbo_Products&id=122" type="text/javascript">

更多产品图片：

产品详细介绍

H-250 气动平面烫金机 Pneumatic flat hot stamping machine

H-250 气动平面烫金机功能特点

1 西门子LOGO！控制器控制，确保机器运行稳定可靠。
2 采用欧姆龙温控器，确保发热温度稳定，保证烫印质量。
3 曲肘机构设计，压缩空气消耗少，压力强劲。
4 烫印压力、温度、烫压时间可调。
5 工作台可自动前后移动，便于安全快速操作。
6 工作台可前后、左右、旋转调节。
7 自动送纸、收纸，并可调。
8 加装光电管（电眼）后可对带接点的热转印纸进行跟踪到位控制。
9 烫印头高度升降可调，可烫印较大的工作。
10 设有安全防护装置，保障操作者的安全。

H-250 气动平面烫金机技术参数

烫板面积:180×230mm
烫板高度调节量 :300mm
烫印最大整圆直径: φ70mm
烫印温度选择范围 :室温~280度
烫金纸卷绕长度:≤300mm
最大烫印压力: 2000kgf (7bar)
最大烫印速度: 1000pcs/hr
电源 :110/220V 60/50Hz
发热功率: 2000W
耗气量: 107L/min
重量：287kg

Feature

1.Siemens LOGO PLC is used for control together with LCD display to ensure high reliability and stability;
2.Omron Temp.Controller is adopted, so temp.control is accurate and reliable;
3.Adjustment on stamping pressure, temperature and speed available;
4.Crank mechanism design provides strong pressure with little loss;
5.5-digit auto counter built in;
6.Worktable moves lengthwise automatically. It is good for safe and quick operation;
7.Adjustment available on worktable front/rear, left/right and plane angle;
8.Foil feeding and collecting are automatic and adjustable;
9.The foil with dots can be traced and controlled with a photo sensor installed;
10.Protecting device ensures the operator’s safety;
11.The adjusting range of stamp height is wide, so substrate with large size can be printed.

Parameter

Max. stamping pressure: 19600N;
Max. stamping height: 300mm;
Size of stamping plate: 180mm×230mm;
Stamping temperature adjustable range: 0-280℃;
Heating wattage: 2000W;
Stamping foil winding length: ≤300 mm;
Max. stamping speed: 1000pcs/hr;
Air consumption: 107Litre/min;
Power: 110/220V 60/50Hz;
Outline dimension: 650×1030×1650mm;
Weight: 287Kg.

气动仿形（曲面、多边形、异形）烫金机H-200M

产品名称：气动仿形（曲面、多边形、异形）烫金机

language="javascript" src="HitCount.asp?id=121&LX=Qianbo_Products" type="text/javascript"> language="javascript" src="HitCount.asp?action=count&LX=Qianbo_Products&id=121" type="text/javascript">

更多产品图片：

产品详细介绍

H-200M 气动仿形（曲面、多边形、异形）烫金机 Pneumatic hot stamping machine with profile modeling and rubber roller

H-200M 气动仿形（曲面、多边形、异形）烫金机功能特点 Feature

1 设有仿形机构，能烫印普通烫金机无法烫印的各种多边形，异形面。
2 仿行机构带动工件旋转，胶辊旋转传热烫印。
3 微电脑程序控制，液晶显示所有控制功能（可选用中英文字幕）操作简单方便。
4 烫印压力、温度、速度均可调。
5 烫印头升降可调。
6 内设五位自动计数器。
7 工作台可前后左右调节。
8 使用风油转换装置，保证工件平稳旋转烫印。
9 加装平面转印工作台后，可实现平面烫印。

1.Microprocessor control and LCD display (English version available) allow simple operation;
2.Rubber roller contacts with substrates in linear form to avoid pin holes on stamping surface;
3.High precision photo sensor is used to monitor and control the feeding of foil with dots and a timer is used for the foil without dots;
4.Stamping head height is adjustable to meet the requirements for different substrates with various heights;
5.Worktable can be adjusted forward/bakcward and left/right, and turned slightly;
6.Profiling mechanism ensures proper stamping on irregular substrates;
7.5-digit counter built in;
8.Capable of adjusting the stamping pressure, temperature and speed;
9.Using pneumatic-hydraulic conversion cylinder to ensure smooth stamping;
10.Auto foil feeding and collecting and the feeding length adjustable.

H-200M 气动仿形（曲面、多边形、异形）烫金机技术参数 Parameter

烫印工件最大直径(Max. diameter)	φ200 mm
烫印温度选择范围(Stamping temp. range)	Ambient~300℃;
最大工件高度(Max. work piece height)	300 mm
烫印压力选择范围(Stamping pressure)	≤80kgf (7bar)
最大烫印速度(Max. Printing speed)	400 pcs/hr
电源(Power)	110/220V 50Hz
发热功率(Heating power)	1200 W
耗气量(Air consumption)	≤145 L/min
外形尺寸(Dimensions)	1650x950x1850 mm
重量(Weight)	200Kg

气动平面烫金机H-200B

产品名称：气动平面烫金机

language="javascript" src="HitCount.asp?id=120&LX=Qianbo_Products" type="text/javascript"> language="javascript" src="HitCount.asp?action=count&LX=Qianbo_Products&id=120" type="text/javascript">

更多产品图片：

产品详细介绍

H-200B 气动平面烫金机 Pneumatic flat hot stamping machine

H-200B 气动平面烫金机功能特点 Feature

1 微电脑程序控制，气动元件驱动。
2 内置烫印平面和曲面控制程式；加装烫印圆面装置后可烫印圆面工件。
3 可实现手动、半自动、及自动操作，调试方便。
4 自动送纸、收纸、并可调。
5 工作台可自动进出烫印位置，便于取放工件。
6 工作台前后左右可微调，还可调校角度。
7 烫印压力，温度，时间可调。
8 内设四位计数器。
9 烫印头高度可调。
10 本机构造稳固耐用，调校简易。

1.Microprocessor control and pneumatic component drive for easy operation;
2.Four-digit auto counter built in;
3.Control program for flat/cylindrical stamping stored and cylindrical stamping available on relevant fixture attachment;
4.Manual/semi-auto/auto operation available and adjustment easy;
5.Auto foil winding and foil collecting length adjustable;
6.Worktable auto moving into/out of stamping position to facilitate substrate loading/unloading;
7.Stamping pressure/temperature/speed all adjustable;
8.Stamping head height adjustable;
9.Structure solid and durable.

H-200B 气动平面烫金机技术参数 Parameter

烫板面积(Heating plate size )	150x210 mm
工作台尺寸(Work table size)	170x220 mm
烫印头行程(Stamping stroke)	50 mm
烫印温度选择范围(Stamping temp. range)	Ambient~280℃;
最大工件高度(Max. work piece height)	200 mm
烫印压力选择范围(Stamping pressure)	≤800kgf
最大烫印速度(Max. Printing speed)	1000 pcs/hr
电源(Power)	110/220V 60/50Hz
发热功率(Heating power)	1500 W
气源压力(Max.Pressure)	4~7 bar
耗气量(Air consumption)	≤63L/min
外形尺寸(Dimensions)	600x1605x660 mm
重量(Weight)	180 Kg
